The table explains which Bluetooth version is installed in which device version.

The identification is based on the device revision level.


Column 3:

Bluetooth Class 1, Version 4.0 (LE)

Note: The 123 Scan Utility plugin is automatically detected and updated by the Zebra Update Server.


Column 4:

Bluetooth Class 1, Version 5.1 (LE)

Note: The 123 Scan Utility plugin must be manually installed for the BARTEC Ex version. See the article about plugins.


Column 1Column 2Column 3Column 4
Part numberScan engineBluetooth Class 1, Version 4.0 (LE)Bluetooth Class 1, Version 5.1 (LE)
17-A1S4-2HP1SE4750-HP
4 or older
5 or newer
17-A1S4-2HP100KRSE4750-HP
3 or older
4 or newer
17-A1S4-2HP100CNSE4750-HP
4 or older
5 or newer
17-A1S4-2HP100JPSE4750-HP
no revision
1 or newer
B7-A2S4-2HP1SE4750-HP
no revision
1 or newer
B7-A2S4-2HP100KRSE4750-HP
no revision
1 or newer
B7-A2S4-2HP100CNSE4750-HP
no revision
1 or newer
B7-A2S4-2HP100JPSE4750-HP
no revision
1 or newer
B7-A2S4-2XR1
SE58-XR
no version existingall versions



Identifying the Revision Level:

The revision level can be identified on the nameplate.

A number following the BARTEC logo indicates the revision level.


Relevant articles:

User manual for the BCS36x8ex Barcode Scanner - see chapter 9.1.3

Zebra 123 Scan Utility - a wizard for configuring and programming the scanners

BCS36x8ex Plugin for Zebra 123 Scan Utility
